Installation Temperature
Thickness
Uncoated
Coated
Operating Temperature
Minimum
Maximum
Material
Description
Cable Clips are widely used across industries in managing cables and wires by firmly securing them to a surface such as a wall, floor or ceiling.
TyClip nail cable clips conform to CE and ROHS specifications and are made of impact modified polyethylene, which provides excellent stress and creep resistance. All our cable clips come with a high quality nail attached so as to maximize customer value by reducing application time and cost.
Cable clips are readily available in all sizes in white colour. Other colours can be manufactured against orders.
• Nails are supplied in an assembled condition to save time and money. The nails are electrogalvanized so that they do not rust easily and hardness of the nail is typically HRC 40.
• Cable clips are a must have for any toolkit, no matter what cables you need to secure. Within the range we offer there is a product to suit every need.
• Although the products look small they are made to a high quality standard and with great longevity.
• The clips are Fixable, with good elasticity which are able to bear high strengths and not break.
| Product Code | Height mm |
Circle Path Diameter-mm |
Nail Size mm |
Remarks |
|---|---|---|---|---|
| Round | 7.5 | 1.6 X 16.5 | ||
| Flat | 12 X 6 | 1.6 X 16.5 | ||
| Oval | 15.2 X 11.4 | 1.7 X 18 | ||
| 4MM | 5.3 | 4 | 1.7 X 15 | |
| 5MM | 6 | 5 | 1.7 X 15 | |
| 6MM | 8 | 6 | 1.8 X 16 | |
| 7MM | 8.6 | 7 | 1.8 X 18 | |
| 8MM | 9.5 | 8 | 1.9 X 19 | |
| 9MM | 10.7 | 9 | 2.0 X 23 | |
| 10MM | 11.5 | 10 | 2.1 X 23 | |
| 12MM | 13.5 | 12 | 2.2 X 25 | |
| 14MM | 16.5 | 14 | 2.3 X 30 | |
| 16MM | 18 | 16 | 2.35 X 32 | |
| 18MM | 20.5 | 18 | 2.6 X 38 | |
| 20MM | 22.2 | 20 | 2.7 X 40 | |
| 25MM | 26.8 | 25 | 3.0 X 50 | |
| 32MM** | 33.8 | 32 | 3.3 X 55 | Double Nail Clips |
| 40MM** | 42.6 | 40 | 3.3 X 65 | Double Nail Clips |
